Server Architecture

Server Architecture

A high-level overview of how FlyWP structures and isolates services on your server.

Every FlyWP server follows the same architecture: a hardened Ubuntu host running Docker, with each WordPress site isolated in its own container. Shared services like MySQL and Redis run as server-level containers, while per-site services (PHP, Nginx or OpenLiteSpeed) run inside each site’s container.

Operating System

FlyWP provisions servers on Ubuntu 22.04 LTS or Ubuntu 24.04 LTS. LTS (Long Term Support) releases receive security patches for five years, providing a stable and well-supported foundation.

Docker-Based Isolation

Docker is the cornerstone of FlyWP’s architecture. Every site runs inside its own container, which provides:

• Process isolation — a crash or runaway process in one site cannot affect another
• File system isolation — each site has its own file system; sites cannot read or write each other’s files
• Resource boundaries — containers can be individually monitored for CPU, RAM, and disk I/O

Docker Configuration

Setting	Value
Storage driver	overlay2
Network subnet pool	172.80.0.0/16
Per-network allocation	/24 (254 usable addresses)
Log driver	JSON file
Max log size	100 MB per file
Max log files	3 (rotated automatically)

System User

All operations run under the fly user, which has both sudo and Docker group access. The root user is not used for day-to-day operations. SSH password authentication is disabled — only key-based access is allowed.

Server-Level Services

These services run once per server and are shared across all sites:

Service	Purpose
MySQL	Relational database engine — each site gets its own database and user
Redis	In-memory cache — each site connects to its own logical database
Docker Engine	Runs and manages all containers
SSH	Secure remote access on port 22
Cron	System-level scheduled tasks
Supervisor	Manages long-running background processes (queue workers, daemons)
UFW	Firewall management
Unattended Upgrades	Automatic security patching

Per-Site Services

Each site container includes its own set of services:

Service	Options
PHP	7.4, 8.0, 8.1, 8.2, 8.3, or 8.4 — selected per site, not per server
Web Server	Nginx or OpenLiteSpeed — selected per site
SSL	Let’s Encrypt certificates with automatic renewal

This means two sites on the same server can run entirely different PHP versions and web servers without conflicts.

Tip

Choosing the PHP version and web server per site (rather than per server) gives you maximum flexibility. You can run a legacy site on PHP 7.4 alongside a modern site on PHP 8.4 on the same server.

How Sites Share Infrastructure

Although sites are isolated at the container level, they share certain server-level resources:

• Ports 80 and 443 — a reverse proxy (Nginx) routes incoming HTTP/HTTPS traffic to the correct site container based on the domain name
• MySQL — all sites connect to the same MySQL instance, but each site has a dedicated database and user with access limited to that database only
• Redis — all sites connect to the same Redis instance, but each uses a separate logical database to avoid key collisions

Note

Sharing MySQL and Redis at the server level is efficient for most workloads. If a single site requires dedicated database resources, consider placing it on its own server.

Security Layers

FlyWP applies multiple security measures at the server level:

• SSH hardening — password auth disabled, host keys regenerated at provision time
• UFW firewall — only ports 22, 80, and 443 open by default
• Automatic security patches — applied during the maintenance window via unattended-upgrades
• Docker isolation — containers cannot access each other’s processes or files
• Non-root operations — everything runs as the fly user
